Gupta, Khatri, Deepak, and Khatri: A study of Ki 67, p53 and their combination as immunomarkers in squamous cell carcinoma of oral cavity


Introduction

Oral cancer is the most common cancer and constitutes a major health problem in the world; being a major cause of death. Although representing 2-4%of the malignancies in the west, this carcinoma accounts for almost 40%of all cancers in the Indian subcontinent.1

In India, oral cavity cancers are the most common cancers in the males and third most common in females.2 Oral cavity includes lip ,floor of the mouth, oral tongue(anterior 2/3), buccal mucosa, gingiva, retromolar trigone, hard palate, base of tongue, tonsillar area and soft palate. Squamous cell carcinoma represents 90% to 95% of the oral cavity malignant neoplasm. Most cases occur in men over the age of 50, although the relative incidence among women and younger patients seem to be increasing. Some cases have been documented in children, particularly in the tongue.3

The prognosis for patients with oral squamous cell carcinoma that is treated early is much better, with 5 year survival rates as high as 80%.

A significant proportion of oral squamous cell carcinoma develop from premalignant lesions such as leukoplakia and oral submucosal fibrosis. Histological examination of tissue remains the gold standard for diagnosis and identification of malignant oral lesions.1

Tobacco and alcohol remain the most important etiologic factors. Consumption of tobacco and betel quint can cause genetic and molecular alterations in clinically district oral premalignant lesions and conditions 4

Infection by human papilloma virus (H.P.V.) and herpes simplex virus (H.S.V) are considered of high risk cancer development.5, 6

Squamous cell carcinoma can be well differentiated (histological grade I) or moderately (histological grade II) or poorly differentiated (histological grade III). The staging of this neoplasia is done according to the TNM system of the international union against cancer with assessment of tumor size and lymph node involvement. The prognostic evaluation of this neoplasia is given by histological and immune histochemical finding, including staging, histological grade, tumor size, lymph node involvement, immune histochemical expression of p53 and Ki 67. 7, 8

Molecular level changes in the lesion occur before clinical and histopathological changes. Molecular biological markers have been suggested to be of value in the diagnosis and prognostic evaluation of the lesions. Markers of proliferation, epithelial differentiation and genomic markers could potentially be good candidates for improving the prognostic evaluation of precursors of oral cancer.

In recent years, the number of molecular based assays has increased but histopathology remains the gold standard for most diagnostic and therapeutic decisions. Tumor suppressor genes, oncogenes, cell proliferation markers, angiogenic markers and cell adhesions molecules have been studied as potential tools to predict the prognosis of patients with oral squamous cell carcinoma.9

The staging systems are mostly clinical staging, based on the best possible estimate of the extent of disease before first treatment. Imaging techniques like computed tomography, magnetic resonance imaging (MRI), positron emission tomography (PET), and ultrasonography may be utilized and, in advanced tumor stages, have added to the accuracy of primary tumour(T) and nodal (N)staging. Anydiagnostic information that contributes to the overall accuracy of the pre-treatment assessment should be considered in clinical staging and treatment planning. When surgical treatment is carried out, cancer of the head and neck can be staged using all information available from clinical assessment, as well as from pathologic study of resected specimen.10

In squamous cell carcinoma of oral cavity, p53 and Ki-i 67 are related to large tumors metastatic to lymph nodes and poor prognosis.11

p 53 is known as the "guardian of genome" is a tumor suppressor gene. P53 assists in DNA repair by arresting cell cycle in G1 phase and inducing the DNA repair genes. A cell with damaged DNA that cannot be repaired is directed by P53 to undergo apoptosis. With homozygous loss of P53, DNA damage goes unrepaired; mutations become fixed in dividing cells, and this leads to malignant transformation of the cell.12 Ki-67 is associated with cell proliferation. The role of Ki-67 as a prognostic marker in various neoplasms has been discussed widely in several studies, albeit with conflicting and debatable results.13

Materials and Methods

The prospective study was done in department of Pathology, N.I.M.S. medical college during the period of 2015 to 2019. The study was carried out with 108 cases of oral cavity squamous cell carcinoma with neck lymph node resection. Processing and staining of the specimen was done. The haematoxylin and eosin along with immune histochemically stained sections were examined. The histological grading of the tumors were done as well, moderate or poorly differentiated according to world health organization (3). As to lymph node involvement; the criteria used was the presence of metastasis seen on microscopy. The cases were broken down into two groups: 1-Cases with negative metastatic lymph nodes and 2: cases with positive metastatic lymph nodes. As to the histological grade of the neoplasia, the cases were broken down into two groups:1 Low grade (including grade I/well differentiated) and (2) high grade (including grades II and III / moderately and with little differentiation). As to pathological staging (pT) of the neoplasia, the cases were broken down into two groups: (1) lesions with local involvement (including pT1, p T2, pT3) and (2) lesions involving neighbouring structures (pT4).

All the immunostained sections of different grades are to be scanned randomly at 100 x magnification for the most densely labelled areas. Then nuclear counting is performed at 400x. A total of 1000 nuclei are counted in the most densely labelled microscopic fields. Counting is carried out in a systemic manner using a grid by keeping in mind not to repeat tumor nuclei while counting. Vascular endothelial cells, lymphocytic cells and necrotic areas were excluded from counts. The MIB –I and p53 labelling indices were expressed as the percentage of MIB -1 and P53 immunolabelled tumor nuclei per 1000 tumor nuclei counted. The following quantification was used.11

Negative expression: 0 to 09% of the neoplastic cells having antibody expression and the Positive expression:10 to 100% of neoplastic cells having antibody expression.

Results

The maximum number of cases was found to be in the age group of 40-60 years (61.8%), mostly being men (85.1%). Female comprised of only 14.9% of the patients.

Maximum number (92.6%) of the patient’s chewed tobacco, followed by smoking (77.78%) and alcohol drinking (55.56%). The most common site of cancer was buccal mucosa (53.7%)

All cases were subjected to immunohistochemistry for Ki 67 and p53. Positive expression of Ki 67 detected was in 92 cases and p53 was detected in 72 cases. Both Ki -67 and p53 was positive in 58 cases.

As to pathological staging, 92(85.2%) patients had tumors which did not invade adjacent structures(Pt1, 2,3) and 16 had tumors invade adjacent structures(pT4), corresponding to 14.8%. Out of non invading 92 cases 60(65.2%) were positive for p53 and out of 16 invading cases 12 (75%) were positive for p53. While in histological grading 48(44.45%) were low grade and 60 (55.6%), were high grade. Out of 48 low grade cases 26(54.1%) cases and out of 60 high grade cases 46(76.6%) were positive for p53. Both pathological staging and histopathological grading did not show any significant statically p value.

Lymph node status was seen in all cases. Out of 108 cases, lymph node were positive in 48(44.4%)cases and 60(55.6%) cases were negative. Out of 48 lymph node positive cases, 40(83.3%) cases were positive for p53 and 8(16.7%) were negative for p53. Out of 60 lymph node negative cases, 32(53.3%) cases were p53 positive and remaining 28(46.7%) were p53 negative. The relationship of P53 expression was statistically significant when compared with lymph node status.

Ki -67 marker was tested in all 108 cases. Out of total 108 cases 92 (85.2%) were found to be positive for Ki -67 and only 16(14.8%) were found negative. Out of 48 low grade cases 14(29.2%) cases and out of 60 high grade cases 44(73.3%) were positive for p53and Ki 67 which was statistically significant. The relationship of p53 and Ki -67 expression was statistically significant when compared with lymph node status.

Figure 1

TNM staging of 108 cases of OSCC

https://s3-us-west-2.amazonaws.com/typeset-media-server/daf6c870-7a5d-4606-9175-6359b813ce2bimage1.png
Table 1

1: Immunoexpression of p53 and Ki-67

Negative Positive
p53 36(33.4%) 72(66.6%)
Ki-67 16 (14.8%) 92(85.18%)
Figure 2

Distribution of variable in 108 OSCC by p53 status

https://s3-us-west-2.amazonaws.com/typeset-media-server/daf6c870-7a5d-4606-9175-6359b813ce2bimage2.png
Figure 3

Pathological Staging and p53 Status

https://s3-us-west-2.amazonaws.com/typeset-media-server/daf6c870-7a5d-4606-9175-6359b813ce2bimage3.png
Table 2

Distribution of Social habits among the 108 cases of OSCC

Ever user Never User
Smoking 84(77.78%) 24(22.22%)
Tobacco chewing 100(92.6%) 8(7.4%)
Alcohol 60(55.56%) 48 (44.44%)
Figure 4

Distribution of variable in 108 cases by Ki67

https://s3-us-west-2.amazonaws.com/typeset-media-server/daf6c870-7a5d-4606-9175-6359b813ce2bimage4.png
Figure 5

Pathological Staging and Ki-67 Status

https://s3-us-west-2.amazonaws.com/typeset-media-server/daf6c870-7a5d-4606-9175-6359b813ce2bimage5.png
Figure 6

Both Ki-67 and p53 expression in relation to Histological grading

https://s3-us-west-2.amazonaws.com/typeset-media-server/daf6c870-7a5d-4606-9175-6359b813ce2bimage6.png
Figure 7

Both Ki-67 and p53 expression in relation to Lymph-Node Status

https://s3-us-west-2.amazonaws.com/typeset-media-server/daf6c870-7a5d-4606-9175-6359b813ce2bimage7.png
Figure 8

Both Ki-67 and p53 expression in relation to Pathological Staging

https://s3-us-west-2.amazonaws.com/typeset-media-server/daf6c870-7a5d-4606-9175-6359b813ce2bimage8.png
Figure 9

Moderately differentiated squamous cell carcinoma of tongue (H&E, 100x)

https://s3-us-west-2.amazonaws.com/typeset-media-server/daf6c870-7a5d-4606-9175-6359b813ce2bimage9.png

Figure 10

Moderately differentiated squamous cell carcinoma of tongue (H&E, 400x)

https://s3-us-west-2.amazonaws.com/typeset-media-server/daf6c870-7a5d-4606-9175-6359b813ce2bimage10.png

Figure 11

Ki-67 immunopositivity in moderately differentiated squamous cell carcinoma of tongue (400x)

https://s3-us-west-2.amazonaws.com/typeset-media-server/daf6c870-7a5d-4606-9175-6359b813ce2bimage11.png

Figure 12

p53 immunopositivity in moderately differentiated squamous cell carcinoma of tongue (400x)

https://s3-us-west-2.amazonaws.com/typeset-media-server/daf6c870-7a5d-4606-9175-6359b813ce2bimage12.png

Figure 13

Ki-67 immunopositivity in poorly differentiated squamous cell carcinoma of buccal mucosa (400x)

https://s3-us-west-2.amazonaws.com/typeset-media-server/daf6c870-7a5d-4606-9175-6359b813ce2bimage13.png

Figure 14

p53 immunopositivity in poorly differentiated squamous cell carcinoma of buccal mucosa (400x)

https://s3-us-west-2.amazonaws.com/typeset-media-server/daf6c870-7a5d-4606-9175-6359b813ce2bimage14.png

Figure 15

Ki-67 immunopositivity in a case of squamous cell carcinoma of buccal mucosa with lymph node matastasis (400x)

https://s3-us-west-2.amazonaws.com/typeset-media-server/daf6c870-7a5d-4606-9175-6359b813ce2bimage15.png

Figure 16

p53 immunopositivity in a case of squamous cell carcinoma of buccal mucosa with lymph node matastasis (400x)

https://s3-us-west-2.amazonaws.com/typeset-media-server/daf6c870-7a5d-4606-9175-6359b813ce2bimage16.png

Figure 17

Muscle invasion in a case of squamous cell carcinoma of buccal muscosa (H&E, 100x)

https://s3-us-west-2.amazonaws.com/typeset-media-server/daf6c870-7a5d-4606-9175-6359b813ce2bimage17.png

Figure 18

Muscle invasion in a case of squamous cell carcinoma of buccal muscosa (H&E, 400x)

https://s3-us-west-2.amazonaws.com/typeset-media-server/daf6c870-7a5d-4606-9175-6359b813ce2bimage18.png

Discussion

Oral cavity and tongue carcinomas have been broadly studied and discussed. Oral squamous carcinomas, though its incidence and biological behaviour, continue to represent a health problem worldwide. Recent studies have clearly shown the importance of immunohistochemistry in the evaluation of predictive values and prognosis of oral cavity squamous cell carcinomas. Although the lesions are easily accessible for clinical examination, their prognosis can be difficult to assess in the context to location variability, risk factors, histopathological and molecular aspects involved in their appearance and progression.

The study aims at assessing the p53 and Ki -67 immunohistochemical markers and to correlate the expression of these markers with other prognostic factors such as age, sex, lymph node status, histological staging and histological grading. In our study, the maximum number of cases was found to be in the age group of 40-60 years (61.8%), mostly being men (85.1%). Female comprised of only 14.9% of the patients. Thus the male to female ratio in our study is 5.7:1. Most number of cases were in the fourth and fifth decades of life.14 Male are affected more often than females because of heavier indulgence in both tobacco and alcohol habits in most countries. In India the highest rates of intraoral cancer may be found in women who chew tobacco heavily.15 High proportion of cases among males may be due to high prevalence of tobacco consumption habits in them, coupled with smoking whereas in our society females less commonly indulge in tobacco smoking.16

In our study group, maximum number (92.6%) of the patients chewed to bacco, followed by smoking (77.78%) and alcohol drinking (55.56%). The most common site of cancer was buccal mucosa (53.7%) followed by tongue (29.63%) comparable to other studies.17 However it is mentioned in world health organization classification of tumors that the most sites vary geographically reflecting different risk factors.9

In India, where tobacco chewing along with betel nuts consumption and reverse smoking(placing the lit end in the mouth) arepractised, there is striking incidence of oral cancer.18

The wild form of P53 plays an important role in arresting the cells with damaged DNA that pass from G1 phase to S phase of cellular cycle and in inducing their apoptosis, the alteration of the expression being documented in various localisations of malignant cells. The positivity percentage for p53 in squamous oral carcinomas varies in different studies from 0-100%, correlating to the severity of the injury.19 Some authors have shown its correlation with degree of differentiation (2), while others have refuted this association. 19

In our study p53 marker was done in all 54 cases. As to pathological staging ,92(85.2%)patients had tumors which did not invade adjacent structures (pT1,2,3) and 16 had tumors invading adjacent structures (pT4), corresponding to 14.8%. Out of non invading 92 cases 60 (65.2%) were positive for p53. While in histological grading 48(44.4%) were low grade (well differentiated), and 60(55.6%), were high grade (moderately and poorly differentiated). Out of 48 low grade cases 26(54.1%) cases and out of 60 high grade cases 46(76.6%) were positive for p53. However both pathological and histological grading were not statistically significant when co related with p53 positivity. In our study, the marker showed expression in all layer of dysplastic epithelium adjacent to oral squamous cell carcinoma in 40% of cases. Also, the suprabasal expression of p53 is considered by some authors as being a risk factor for subsequent occurrence of epithelial dysplasia and oral squamous cell carcinoma.as in other studies. 20, 21, 22, 23

A significantly increased positivity with increasing tumor grade was noticed (24). This indicates a higher p53 expression indicates poorer prognosis. The relationship between p53 mutations and tumor grade has been evaluated in many studies.24

Lymph node statuses were also seen in all cases. Out of total 108 cases, lymph node were positive in 48(44.4%) cases, and 60(55.6%) cases were negative for lymph node, and out of 48 positive cases, 40(83.3%) cases are seen to be positive for p53. The relationship of p53 expression was statistically significant when compared with lymph node status as in other study 11, 25, 26, 27

Ki 67 marker is tested in all 108 cases. Out of total 108 cases 92 (85.2%) were found to be positive for Ki 67 and only 16(14.8%) were found negative. As to the pathological staging 92(85.2%) patients had tumors which did not invade adjacent structures (pT1,2,3) and 08 had tumors invading adjacent structures (pT4), corresponding to 14.8%. Out of non invading 92 cases 78 cases (84.8%) were positive for Ki -67 and out of 16 invading cases (87.5%) were positive for Ki 67. While in histological grading 48 (44.4%) were low grade (well differentiated), and 60 (55.6%), were high grade (moderately and poorly differentiated). Out of 48 (44.4%) low grade cases 34(70.8%) cases and out of 60 (55.6%) high grade cases 58 (96.7%) were positive for Ki 67. Pathological staging did not show any statistical significance while histological grading show statically significant p value.

The Ki -67 immunoreaction in well differentiated oral squamous cell carcinoma revealed a medium PI-Ki-67 of 22%, in moderately differentiated oral squamous cell carcinoma was 32 %,and a medium value of 53% in case of poorly differentiated in concordance with other study,[27,86]27 69In our study out of total 108 cases, lymph node were positive in 48(44.4%) cases, and 60(55.65) cases were negative, and out of 48 positive cases 42(87.5%) cases were seen to be positive for KI-67. The relationship of Ki -67 expression did not show statically significant p value when compared with lymph node status.

Statically analysis of Ki-67 also carried out with other variables in our study and it did not prove to be significant when compared to age, sex, gender and tumor volume. The literature shows that the co expression of p53 and Ki 67 takes part in the carcinogenesis of oral cavity squamous carcinomas, thus causing cell proliferation.28 The negative combination of these two markers(p53/Ki-67) is associated to a lower recurrence incidence (p=0.02), lower loco regional recurrence rate (p = 0.01) and lower incidence of a second primary tumor (p=0.045), as well as longer disease –free survival(p=0.02). In our study simultaneous expression of both the markers p53 and Ki 67 happened in 53.70% of cases and it was statically significant when compared with lymph node status(p=0.0473) and histological grading (p= 0.0022). In our study simultaneous expression of both the markers p53 and Ki -67 happened in 53.70% of cases and it was statically significant when compared with lymph node status(p=0.0473) and histological grading (p=0.0022); but it did not prove to be significant with other variables such as age, sex, histological staging.

Conclusion

Oral squamous cell carcinoma is significantly associated with elderly age group and with males. Commonest site being buccal mucosa and is most commonly associated with tobacco chewing. p53 was significantly associated with cases with metastasis to neck lymph node an Ki 67 was statically significant when compared with histological differentiation. The co expression of p53 and Ki-67 was significantly associated with those cases with positive lymph node status and higher histological grading.

Source of Funding

None.

Conflict of Interest

None.

References

1

R Mehrotra A Gupta M Singh Application of cytology and molecular biology in diagnosing premalignant or malignant oral lesionsMol Cancer2016511

2

K Park Parks textbook of preventive and Social medicine18th edn.Jabalpur: M/s Banasidas Bhaot2005

3

J Mork A K Lie E Glattre G Hallmans E Jellum Koskela Papillomavirus infection as a risk factor for squamous -cell carcinoma the head and neckN Engl J Med200115112531

4

P. A. Wingo L. A. G. Ries G. A. Giovino D. S. Miller H. M. Rosenberg D. R. Shopland Annual Report to the Nation on the Status of Cancer, 1973-1996, With a Special Section on Lung Cancer and Tobacco SmokingJNCI J National Cancer Ins199991867590

5

Ronald H. Spiro Oscar Guillamondegui Augusto F. Paulino Andrew G. Huvos Pattern of invasion and margin assessment in patients with oral tongue cancerHead & Neck199921540813

6

G Lozano The oncogenic roles of p53 mutants in mouse models.Current opinion in genetics & development2007176670

7

R E Nakhleh Myogenic differentiation in spindle cell (sarcomatoid) carcinomas of the upper aerodigestive tractAppl Immunohistochem199315868

8

Anak Iamaroon Udomrat Khemaleelakul Surawut Pongsiriwet Jarupan Pintong Co-expression of p53 and Ki67 and lack of EBV expression in oral squamous cell carcinomaJ Oral Pathol Med2004331306

9

João Massano Frederico S. Regateiro Gustavo Januário Artur Ferreira Oral squamous cell carcinoma: Review of prognostic and predictive factorsOral Surg, Oral Med, Oral Pathol, Oral Radiol, Endodontol20061026776

10

AJCC Cancer staging ManualAmerican Joint committee on cancer 7th Edn.20102230

11

Rafael Da Ros Motta C G Zettler E Cambruzzi G P Jotz R B Berni Ki -67 and p53 corelation prognostic value in squamous cell carcinomas of the oral cavity and tongueBraz J Otorhinolaryngol20097545549

12

T P Stricker V Kumar Neoplasia V Kumar A Abbas N Fausto NeoplasiaRobbins and Cotran Pathologic Basis of Disease88th edn.ElsevierPhiladelphia2010259330

13

T P Stricker V Kumar N Fausto V Kumar N Fausto N Fausto NeoplasiaRobbins and Cotran Pathologic Basis of Disease8ElsevierPhiladelphia2010259330

14

P Sharma S Saxena P Aggarwal Trends in the the epidemiology of oral squamous cell carcinoma in western UP: An institutional studyIndian J dent Res2019213169

15

L Barnes J W Evenson P Reichart D Sidransky Pathology and genetics of head and neck tumors,world health Organization classification of tumorsIARC pressLyon2005

16

P Doshi Neena Shah Siddarth A Patel Patel Keyurib Histological grading of oral cancer: A comparison of different systems and their relation to lymph node metastasisNational J Comm Med2011113642

17

Preeti Sharma Susmita Saxena Pooja Aggarwal Trends in the epidemiology of oral squamous cell carcinoma in western UP: An institutional studyIndian J Dent Res20102133169

18

S P Khandelkari PS Bagdey Oral cancer and some epideological factors: A hospital based study Indian J Comm Med20063115762

19

J. A. Regezi R. J. Zarbo E. Regev S. Pisanty S. Silverman D. Gazit p53 protein expression in sequential biopsies of oral dysplasias and in situ carcinomasJ Oral Pathol Med19952411822

20

F A Sousa T C Paradella Y R Carvalho Immunohistochemical expression of PCNA , p53 ,bax and bcl-2 in oral lichen planus and epithelial hyperplasiaJ Oral Sci200951111721

21

F Angiero A Benetti E Rossi Del Sordo R Expression of p16 , p53 and ki 67 proteins in the progression of epithelial dysplasia of the oral cavityAnticancer Res2008285a25359

22

H Kurokawa M Zhang S Matsumoto Y Yamashita T Tanaka T Tomoyose The relationship of the histologic grade at the deep invasive front and the expression of Ki 67 antigen and p53 protein in oral squamous cell carcinomaJ Oral Pathol Med200534106027

23

K Kato S Kawashiri Tanaka A N Noguchi Predictive value of measuring p53 labelling index at the invasive front oral of squamous cell carcinomasPathol Oncol Res20181415761

24

Maimoona Zariwala Stephan Schmid Madeleine Pfaltz Hiroko Ohgaki Paul Kleihues Reinhold Schäfer p53 gene mutations in oropharyngeal carcinomas: A comparison of solitary and multiple primary tumours and lymph-node metastasesInt J Cancer199456680711

25

A Jain Maheshwari G Mehdi K Alam Diagnostic and Prognostic significance of p53 protein expression in squamous .Protein expression in squamous cell lesions of the oral cavity.Int J Otorhinolaryngol200872

26

L R Oliveira A Ribeiro-Silva S Zucolto Prognostic significance of p53 and p63 immunolocalisation in primary and matched lymph node metastasis in oral squamous cell carcinomasActa Histochem2007109538896

27

J Bullwinkel Lu Baron -Lu Demanna Ki -67 protein is aasociated with ribosomal RNA transcription in quiescent and proliferating cellsJ Cell Physiol200620662435

28

Anak Iamaroon Udomrat Khemaleelakul Surawut Pongsiriwet Jarupan Pintong Co-expression of p53 and Ki67 and lack of EBV expression in oral squamous cell carcinomaJ Oral Pathol Med2004331306
